SUMMIT PRIME 540

KEY INFORMATION

SLEEPS

2 (+1 optional)

SEATS

4

MPLM

3300 kg

LENGTH

5413 mm

WIDTH

2050 mm

HEIGHT

2580 mm

SPECIAL FEATURES

  • Easy move table with clever in travel function
  • Lights Under Roof Cabinet with night light function
  • Generous open space concept with SkyRoof®

FEATURES

Swing Wall Bathroom

More work surface thanks to the fold-able extension.

Mocha wood decor
(Grigio Lucente ) world of living, Easy Move table with travel function

TECHNICAL DATA

Vehicle Dimensions

Length:
5413mm
Height:
2580mm
Width:
2050mm
Width:
3450mm
Width:
1905mm

On Board Technology

Fresh Water
85L
Waste Water
100
Heating
Truma Combi 4
Boiler Capacity in L (Approx)
10
Gas bottle box for (kg)
1 x 11 and 1 x 5
Charger in A
16
Battery
12V/95Ah
230 V Sockets
2/1
Refrigerator in L (capacity/including freezer)
ca. 100/8
Absorber/Compressor
Compressor

Living Area

Sleeping places
2 (+1 optional)
Seats/Seatbelts
3/3 (+1 optional)/4 (+1 optional)
Window living room
4
Roof hood with blackout blind
2
Rear bed in mm (approx)
1.960 x 1.200/1.410
Third bed in mm (approx)
1.600 x 720/650 x 100
Possible Isofix connections
1

Weight & Load

MPLM
3300kg
Mass in running order
2695kg
Payload
605kg
